ICU Nursing Bed
Hospital Furniture
Adjustable, comfort-focused, convenience
WG-EHB01
ICU nursing bed (turning bed)
WEGO Medical ICU Nursing Bed features overall lifting, backboard/knee lift, tilt, one-button chair, shortcut function, and electric/manual CPR.
It includes a precision weighing system (0.1KG accuracy) and a left-right tilt (0-17°) for nursing needs.
Overview
WEGO Medical ICU Nursing Bed features overall lifting, backboard/knee lift, tilt, one-button chair, shortcut function, and electric/manual CPR.
It includes a precision weighing system (0.1KG accuracy) and a left-right tilt (0-17°) for nursing needs.
Specifications
parameter
| Bed size | 2275 × 1000mm |
| Bed Board size | 2035×910 mm |
| Maximum load | 250kg |
| Adjustment range | Lifting height 360 mm-820 mm Back lift 0-70°±5° Knee lift 0-45 °± 5 ° Trendelenburg/Reverse Trendelenburg 0-15°± 2 ° Tilt left and right 0 -17 ° |
| Functions | Overall lifting, backboard lifting, knee lifting, back-leg linkage, front-back tilt, left-right tilt, one-button chair position, one-button shortcut function, electric CPR, manual CPR, one-button emergency stop. |
| Weighing function | Equipped with a precision weighing system, the display accuracy can reach 0.1KG. |
| Left and right tilt function | It has left and right tilt function. When in use, the left and right tilt angle is 0-17 ° , and it can be turned over by setting the angle and time to meet clinical nursing needs. |
Configuration List
| Hospital bed | 1 set |
| ABS headboard and tailboard | 1 set |
| ABS guardrail | 1 set |
| Battery | 1 set |
| Casters | 4 pieces |
| Small hand controller | 1 set |
| Nurse hand control | 1 set |
| Mattress | 1 piece |
| Stainless steel infusion stand | 1 set |
| Weighing system | 1 set |
| Optional functions | Guardrail buttons, X-ray transparent backboard, bedsore prevention mattress |
