Sealing Machine
CSSD Accessories
WEGO Automatic Sealing Machine combines sealing and printing. Set pouch quantity and length.
WGMR-30
Sealing Machine
WEGO Automatic Sealing Machine combines sealing and printing. Set pouch quantity and length.
Multiple reels enhance efficiency. Ideal for medical and industrial use, ensuring reliable sealing and labeling.
Overview
WEGO Automatic Sealing and Printing Machine integrates sealing and printing functions into one unit.
Operators can set the desired quantity and length of the paper-plastic pouches to be cut. To improve efficiency, multiple reels can be placed on the holder.
This equipment is designed to be simple yet powerful, suitable for various medical and industrial applications, ensuring consistent and reliable sealing and labeling for each package.
Specifications
Technical Data
Housing Material | Coated Carbon Steel |
Sealing speed | 10±0.5m/min |
Sealing width | 12mm |
Sealing margin | 0~40 mm adjustable |
Heating rate | 180 ℃/40s |
Working temperature | 60~220℃ adjustable |
Temperature control accuracy | ≤1% |
Printing mode | Matrix printer |
Information Export | USB port to save data |
Working environment | 10~40℃ |
Power supply | 220V±10% 50Hz |
Rated power | 400W |
Weight | 11kg |
Size | 472×232×188mm |
Feartures
Main Features
Small and light-weight | |
Intelligent detection and alarm prompt function | |
Touch screen | 7 inch touch screen, with graphical operation interface showing adjustable working parameters and automatic storage function. |
Printer | Built-in printer to print working parameters. |
Temperature control | temperature control accuracy ±1%, working temperature 60~220℃ arbitrary setting. |
High speed heating design | Room temperature reaches to 180℃ in 40s, high efficiency and energy saving, to meet the needs of fast-paced work. |
Auxiliary cooling design | Equipped with microcomputer controlled cooling system to reduce the waiting time of the temperature adjustment from the high temperature sealing to the low temperature sealing. |
Safety | When the sealing temperature exceeds the set value range of working temperature ±4℃, the machine will automatically stop working, effectively ensuring the quality of the sealing and the safe operation of the equipment. |
